Startseite /Produkte/Überzugstärkeprüfer/EC-420 1500um EC-420 Handheld Coating Thickness Gauge

EC-420 1500um EC-420 Handheld Coating Thickness Gauge

10 pieces
MOQ
EC-420 1500um EC-420 Handheld Coating Thickness Gauge
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Warranty: 1 year
Customized support: OEM, ODM, OBM
Model Number: EC-420
Measuring range: 0~1500μm
Accuracy: ±(3%+1μm)
Product name: coating thickness gauge
Website: www.wellzion.com
Grundinformation
Model Number: EC-420
Zahlung und Versand AGB
Packaging Details: Package:Gift box coating thickness gauge
Produkt-Beschreibung

EC-420 1500um handheld coating thickness gauge

Product Overview

This coating thickness gauge has a built-in magnetic induction and eddy current integrated probe, supporting 0~1500μm measurement range,±(3%+1μm) accuracy and 0.1μm resolution.

Function & Benefits
  • Integrated probe of magnetic induction and eddy current
  • Up to 0.1μm resolution
  • Up to ±(3%+1μm)accuracy
  • Up to 0~1500μm measurement range
  • Easy to do zero calibration
  • LCD shows maximum, minimum, average and number
  • Support Continuous measurement
  • Up to 2 times/s measurement speed
  • LCD display with backlight
  • Power off automatically
Specifications

Model EC-420
Probe Probe F Probe N
Measuring principle Magnetic Induction Eddy currents
Measuring range 0~1500μm
Accuracy ±(3%+1μm)
Resolution 0.1μm(0~100μm);1μm(>100μm)
Calibration mode Zero calibration
Statistics No. of readings, mean, minimum, maximum
Units μm, mm, mils
Minimum radius of curvature of substrate Convex 5 mm; Concave 25 mm
Minimum measured area Diameter 20mm
Minimum thickness of substrate 0.30mm 0.05mm
Maximum measuring speed 2 times / second
Display Segment code LCD screen with backlight
Operation buttons Power (Backlight), unit switching and clearing data (Left), statistics and zero calibration (Right)
Operation temperature Temperature:-10℃~50℃;Humidity:20%RH~90%RH(Non-condensation)
Storage temperature Temperature:-10℃~60℃;Humidity:20%RH~90%RH(Non-condensation)
Power supply 9V square battery
Protection class IP40
Size 143mmX85mmX39mm
Material ABS
Weight About 100g(No battery)
Warranty 12 months
